3 F Carbide Endmill CNC Machine Cutter Hand Tools for Metal HRC45 55 60 70 Square Face Milling Cutter Bits End Mill
Overview 3F Carbide Endmill CNC Machine Cutter Hand Tools for Metal HRC45 55 60 70 Square Face Milling Cutter Bits End M
Basic Info
| Model NO. | 1-4*50l, 5-6*50l, 7-8*60l, 9-10*75l, 11-12*75ll |
| Transport Package | Carton |
| Specification | 50-200mm |
| Trademark | YFT |
| Origin | China |
| Production Capacity | 100000pieces/Years |
Product Description
3F Carbide Endmill CNC Machine Cutter Hand Tools for Metal HRC45 55 60 70 Square Face Milling Cutter Bits End MillProduct SpecificationProduct SpecifiProduct Description| Product Name | Carbide End Mill Milling Cutters |
| Material | 100% New Raw Material Carbide |
| Flute | 1 / 2 / 4 / 6 /7 /8 /9 /12 Flutes |
| HRC | 45 / 55 / 58 / 60 / 65 /70 |
| Customized | Our factory supports Size, Coating, Shape, Logo, Sample Test etc. customization. |
| Coating Thickness | 2um-4um |
| Shank Diameter | 1mm-20mm |
| Overall Length | 50mm-200mm |
| Application | General-purpose operation Slotting, Drilling, Profiling |
| Working Machine | CNC (computer numeric controlled) tool and cutter grinder machines |
| Work-piece material | Stainless Steel, Carbon Steel, Aluminum, Cast Iron, Alloyed Metal, Brass, Bronze etc. |
| Grade | Coating | Color | Hv | μm | Friction | Max°C | Application |
| HRC 45 | AlTiN | black | 3300 | 0.6 | 0.7 | 850°C | Suitable for General Steel |
| HRC 50 | AlTiN | black | 3300 | 0.6 | 0.7 | 850°C | Suitable for General Steel |
| HRC 55 | TiSiAlN | bronzed | 3400 | 0.5 | 0.7 | 900°C | General Steel,cast cast iron |
| HRC 60 | AlCrSiN | black | 4000 | 0.4 | 0.35 | 1100°C | High Hard Material, steel, cast iron, etc |
| HRC 65 | nACo3Blue | blue | 4500 | 0.4 | 0.45 | 1200°C | Titanium Alloy, High-temperature Alloy,material, etc |
| Tool size (mm) | Outside Diameter | Shank Blade diameter | Blade length | Overall Length | Flutes |
| 3F-D1*d4*3*50 | 1 | 4 | 3 | 50 | 3 |
| 3F-D1.5*d4*4*50 | 1.5 | 4 | 4 | 50 | 3 |
| 3F-D2*d4*6*50 | 2 | 4 | 6 | 50 | 3 |
| 3F-D2.5*d4*8*50 | 2.5 | 4 | 6 | 50 | 3 |
| 3F-D3*d4*8*50 | 3 | 4 | 8 | 50 | 3 |
| 3F-D4*d4*11*50 | 4 | 4 | 11 | 50 | 3 |
| 3F-D5*d6*13*50 | 5 | 6 | 13 | 50 | 3 |
| 3F-D6*d6*15*50 | 6 | 6 | 15 | 50 | 3 |
| 3F-D8*d8*20*60 | 8 | 8 | 20 | 60 | 3 |
| 3F-D10*d10*25*75 | 10 | 10 | 25 | 75 | 3 |
| 3F-D12*d12*30*75 | 12 | 12 | 30 | 75 | 3 |
| 3F-D12*d12*30*100 | 12 | 12 | 30 | 100 | 3 |
| 3F-D14*d14*45*100 | 14 | 14 | 45 | 100 | 3 |
| 3F-D16*d16*45*100 | 16 | 16 | 45 | 100 | 3 |
| 3F-D20*d20*45*100 | 20 | 20 | 45 | 100 | 3 |
Factory Country/Region:ZhongShan,GuangDong,China
Contract Manufacturing:Buyer Label Offered
Annual Output Value:US$2.5 Million - US$5.0 Million
Main Products: Carbide End Mills , Carbide Rods , Carbide Drills , CNC Insert , Carbide Wood Cutting Tool , ...
Main Markets: North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, Mid East, ...
GuangDong ShanGao Tools is located in hometown of Chinese carbide industry - ZhongShan city. The company has more than 20 years′ experience in design and sale of various kinds of carbide products, main products include: Carbide end mills, carbide rods, indexable inserts, brazed inserts, wire drawing dies, forging dies, wood working tools, saw tips, mining buttons, etc
With excellent quality, strong technical support, and good after sales service, Grewin Carbide brand products are sold to more than 50 countries in the world, such as Europe, USA, south east Asia, Middle East, south America, etc.
We have a professional R&D team, rich market oriented practical experience, strong long-term strategic partner, and a professional installation and commissioning team, striving to provide customers with high quality products and service in the first time!
